DASMIKRO DSK-482 COMPATIBLE ANTENNA-FREE RECEIVER V2 FOR SANWA SSL FH-4 FH-3 M17 M12S M12 MT-44 MT4S MT4 M11X

Name: DASMIKRO DSK-482 COMPATIBLE ANTENNA-FREE RECEIVER V2 FOR SANWA SSL FH-4 FH-3 M17 M12S M12 MT-44 MT4S MT4 M11X
SKU: DSK-482
Availability: InStock

Original price was: $28.00.Current price is: $24.00.

THIS IS DASMIKRO SANWA ANTENNA-FREE RECEIVER VERSION 2

COMPARED TO VERSION 1, VERSION 2 HAS BELOW CHANGES:

1. SSL OUTPUT AVAILABLE

2. CHANGED ‘SIGNAL’ AND ‘GND’ POSITION, FUTABA AND TAMIYA ANTI-REVERSE PLUG NO NEED TO CHANGE THE CABLES POSITION ANY MORE

SKU: DSK-482 Categories: SANWA, SANWA Tags: Antennaless Surface Receiver, DM Racing, Sanwa

DASMIKRO DSK-482 COMPATIBLE ANTENNA-FREE RECEIVER V2 FOR SANWA SSL FH-4 FH-3 M17 M12S M12 MT-44 MT4S MT4 M11X

Description

THIS IS DASMIKRO SANWA ANTENNA-FREE RECEIVER VERSION 2

COMPARED TO VERSION 1, VERSION 2 HAS BELOW CHANGES:

1. SSL OUTPUT AVAILABLE

2. CHANGED ‘SIGNAL’ AND ‘GND’ POSITION, FUTABA AND TAMIYA ANTI-REVERSE PLUG NO NEED TO CHANGE THE CABLES POSITION ANY MORE

Description:

This receiver unit is Sanwa high speed FHSS-4 and FHSS-3 compatible

Features:

1. Sanwa 2.4GHz FH3/FH4 Selectable Via Transmitter

2. High performance CPU enhance precision control feeling

3. 4 channel support

4. Micro size (Antenna-Free: 25.5x22x17.3mm)

5. Added failsafe function

6. Operating Voltage 3.5V – 8.4V:

7. Weight: 5g

8. Battery Voltage Fail-Safe Limit: 3.5-5.0V (FH3) / 3.5-7.4V (FH4)

Compatible Transmitters:

Sanwa M17

Sanwa M12S

Sanwa M12

Sanwa MT44

Sanwa MT4S

Sanwa MT4

Sanwa M11X

Binding procedure：

Step1. Select FH-4 or FH-3 protocol on transmitter and swith to bind page.

Step2. Plug the ‘bind cable’ onto the receiver then power on. The receiver should enter the binding mode for 10 seconds(the led will slowly flash for 10 seconds).

Step3. Operate ‘bind’ operation on transmitter while the receiver led is slowly flashing.

Step4. If you did not make the ‘bind’ operation on transmitter in 10 seconds(receiver led slowly flashing), go back to Setp2 and do it again.

Step5. After binding please power off the receiver and transmitter, unplug the ‘bind cable’. Then power them on to confirm they are bond.

Binding procedure video reference:

https://youtu.be/Icrm-XKENnU

https://youtu.be/s63koLCPXAk
